The display includes a USB port so you can charge your smartphone.
Easy-read backlit display with key info: battery level, power-assist mode, speed, daily and total mileage.
You can get far - up to a maximum possible range of 150 km (at the lowest assistance level, under optimal conditions, with a fully charged battery in perfect condition and with the highest possible capacity.)
Kalkhoff customers receive a ten-year guarantee on all (S-)pedelec frames. Online registration is required.
Indication of illumination level, which reveals the luminous flux (lumens) incident on a surface (m²). The higher the value, the better the level of illumination.
| Crankset | Concept |
| Brakes | Shimano M396, hydraulic disc brake - 180 Brake rotors |
| Brake rotors | 180 |
| Fender | plastic, with edge protector |
| Shifting system | Shimano SLX, 10-speed |
| Kickstand | rear stand, adjustable |
| Headlight | AXA Blueline, LED |
| Permissible Total Weight | 130 kg |
| Rear derailleur | Shimano SLX M670 |
| Shifter | Shimano SLX M7000 |
| Rims | Rodi Blackrock, with eyelets |
| Sprocket description | Shimano HG500 |
| Boitier de pédalier | Integraded in Drive Unit |
| Headlight | Herrmans H-Black MR8, LED |
| Taillight | AXA Blueline, LED |
| Motor | Bosch Performance Line CX, 36 V / 250 W / 75 Nm |
| Display | Bosch Intuvia LCD, with control panel and walk assist |
| Battery | Bosch PowerTube Li-Ion 36 V |
| Wheel diameter / Size | S | M | L | XL | |
|---|---|---|---|---|---|
| A | Size (MM) | 430 | 480 | 530 | 580 |
| B | Effective Top Tube (MM) | 588.2 | 597.1 | 606 | 614.9 |
| C | Head Tube Angle (°) | 72 | 72 | 72 | 72 |
| D | Effective Seat Tube Angle (°) | 73 | 73 | 73 | 73 |
| E | Chainstay (MM) | 485 | 485 | 485 | 485 |
| F | BB Drop (MM) | 65 | 65 | 65 | 65 |
| G | Head Tube Length (MM) | 160 | 170 | 180 | 190 |
| H | Fork Length (MM) | 468 | 468 | 468 | 468 |
| I | Fork Offset (MM) | 45 | 45 | 45 | 45 |
| J | Wheelbase (MM) | 1107.5 | 1116.6 | 1125.7 | 1125.7 |
| K | Stack (MM) | 648.4 | 657.9 | 667.4 | 676.9 |
| L | Reach (MM) | 390 | 396 | 402 | 408 |
