| Cranks | aluminium |
| Remsysteem | Shimano MT420, 4-piston, hydraulische schijfrem - 180 Remschijf |
| Spatbord | plastic, met randbeschermer |
| Schakeling | Enviolo Trekking |
| Standaard model | achterstandaard, instelbaar |
| Toelaatbaar gewicht | 170 kg |
| Versteller | Enviolo Trekking |
| Velgen | Rodi Airline Plus |
| Trapas | Integraded in Drive Unit |
| Vorlamp | Herrmans H-Black MR8, LED |
| Achterlicht | Herrmans H-Trace, LED |
| Type Versnelling | naaf |
| Remsysteem | schijfremmen |
| Motor | Bosch Performance Line 36 V / 250 W / 65 Nm |
| Weergave | Bosch Intuvia LCD, met bedieningspaneel en loopassistentie |
| Accu | Bosch PowerTube Li-Ion 36 V |
| Motor | Bosch Performance Line |
| Aandrijfsysteem | Bosch |
| Wheel diameter / Size | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| A | Grootte (MM) | 430 | 480 | 530 | 580 | 630 |
| B | Effective Top Tube (MM) | 588 | 597.1 | 606 | 614.9 | 624 |
| C | Head Tube Angle (°) | 72 | 72 | 72 | 72 | 72 |
| D | Effective Seat Tube Angle (°) | 73 | 73 | 73 | 73 | 73 |
| E | Chainstay (MM) | 485 | 485 | 485 | 485 | 485 |
| F | BB Drop (MM) | 65 | 65 | 65 | 65 | 65 |
| G | Head Tube Length (MM) | 160 | 170 | 180 | 190 | 200 |
| H | Fork Length (MM) | 468 | 468 | 468 | 468 | 467.5 |
| I | Fork Offset (MM) | 45 | 45 | 45 | 45 | 45 |
| J | Wheelbase (MM) | 1107 | 1116.6 | 1125.7 | 1125.7 | 1144 |
| K | Stack (MM) | 648 | 657.9 | 667.4 | 676.9 | 686 |
| L | Reach (MM) | 390 | 396 | 402 | 408 | 414 |
