| Cranks | aluminium |
| Remsysteem | Magura HS11, hydraulische velgrem |
| Spatbord | plastic, met randbeschermer |
| Schakeling | Shimano Nexus, 8 versnellingen |
| Standaard model | achterstandaard, instelbaar |
| Toelaatbaar gewicht | 130 kg |
| Versteller | Shimano Nexus |
| Velgen | Concept EX |
| Tandwiel | Shimano |
| Trapas | Integraded in Drive Unit |
| Vorlamp | Herrmans H-Black MR4, LED |
| Achterlicht | AXA Blueline, LED met standlicht |
| Type Versnelling | naaf |
| Remsysteem | velgram |
| Motor | Bosch Active Plus, 36 V / 250 W / 50 Nm |
| Weergave | Bosch Intuvia LCD, met bedieningspaneel en loopassistentie |
| Accu | Bosch PowerTube Li-Ion 36 V |
| Motor | BOSCH ACTIVE LINE PLUS |
| Aandrijfsysteem | Bosch |
| Wheel diameter / Size | S | M | L | XL | |
|---|---|---|---|---|---|
| A | Grootte (MM) | 450 | 500 | 550 | 600 |
| B | Effective Top Tube (MM) | 609 | 619 | 628 | 614 |
| C | Head Tube Angle (°) | 72 | 72 | 72 | 72 |
| D | Effective Seat Tube Angle (°) | 75 | 75 | 75 | 73 |
| E | Chainstay (MM) | 490 | 490 | 490 | 480 |
| F | BB Drop (MM) | 65 | 65 | 65 | 65 |
| G | Head Tube Length (MM) | 185 | 195 | 205 | 190 |
| H | Fork Length (MM) | 465 | 465 | 465 | 462 |
| I | Fork Offset (MM) | 45 | 45 | 45 | 44 |
| J | Wheelbase (MM) | 1108 | 1117 | 1126 | 1128 |
| K | Stack (MM) | 672 | 681 | 691 | 674 |
| L | Reach (MM) | 378 | 384 | 390 | 408 |
