Bosch Intuvia LCD, with control panel and walk assist
Battery
Bosch PowerTube Li-Ion 36 V
Drive system
Bosch
Range
100 - 150 km
Charger
Bosch, 2A
Shifting system
Shimano Deore, 10-speed
Shifter
Shimano Deore
Crankset
aluminium
Rear sprocket description
Shimano Deore
Gear Ratio
front: 38, rear: 11-32
Brake caliper
Shimano MT200, 2-piston, hydraulic disc brake
Brake rotors
180
Headlight
Herrmans H-Black MR4, LED
Taillight
AXA Blueline, LED with stand light
Frame
Integrale 0.1, aluminium
Wheelset
No
Rims
Concept, with eyelets
Fork
SR Suntour NEX E25 HLO, lockout
Fender
plastic, with edge protector
Stem
Concept SL, adjustable
Kickstand
rear stand, adjustable
Handlebar
Concept Riser,Tour, Aluminium
Permissible Total Weight
130 kg
Saddle
Kalkhoff Sport Comfort
Shock
No
Seatpost
Patent, suspension
Rear derailleur
Shimano Deore
Pedals
Aluminium, with anti slip protection and reflector
Bottom Bracket
Integrated in Drive Unit
Tires
Schwalbe Energizer Active Plus, 47-622
Carrier
Tour, aluminium
Gear System
derailleur
Brake
disc brake
Chain
Shimano CN-LG50
Travel of suspension fork
63 mm
Grip Description
Herrmans Click
Wheel diameter / Size
S
M
L
XL
Stand Over Height (°)
S
M
L
XL
A
Size (MM)
450
500
550
600
B
Effective Top Tube (MM)
587
596
605
614
C
Head Tube Angle (°)
72
72
72
72
D
Effective Seat Tube Angle (°)
73
73
73
73
E
Chainstay length (MM)
480
480
480
480
F
Bottom bracket drop (MM)
65
65
65
65
G
Head Tube Length (MM)
160
170
180
190
H
Fork construction height (MM)
462
462
462
462
I
Pre-raked fork (MM)
44
44
44
44
J
Wheelbase length (MM)
1100
1110
1119
1128
K
Stack (MM)
645
655
664
674
L
Reach (MM)
390
396
402
408
* Subject to technical modification without notice. Errors and omissions excepted.
