Specificaties
Alles wat je moet weten over deze fiets
|
Type fiets
|
Nee |
|
Motor
|
Shimano Steps E8000 series, 36V / 250 W |
|
Weergave
|
Shimano SC-E6100, LCD Display met loopassistentie |
|
Accu Ampère uur
|
15 Ah |
|
Accu
|
Integrated Li-Ion 36V |
|
Aandrijfsysteem
|
Shimano |
|
Reikwijdte
|
100 - 150 km |
|
Lader
|
Charger, 4A |
|
Schakeling
|
Shimano Deore XT, 10 versnellingen |
|
Versteller
|
Shimano Deore |
|
Cranks
|
aluminium |
|
Achtertandwiel
|
Shimano Deore |
|
Overbrenging
|
voor: 38, achter: 11-36 |
|
Remsysteem
|
Shimano MT420, 4-piston, hydraulische schijfrem |
|
Remschijf
|
180 |
|
Vorlamp
|
Herrmans H-Black MR8, LED |
|
Achterlicht
|
AXA Blueline, LED met standlicht |
|
Beeld
|
Integrale 0.5, aluminium |
|
Wielset
|
Nee |
|
Velgen
|
Rodi Airline Plus |
|
Wielgrootte
|
28" |
|
Spatbord
|
plastic, met randbeschermer |
|
Voorvork
|
SR Suntour NEX E25 HLO, blokkeerbaar, 15 mm doorgaande as |
|
Standaard model
|
achterstandaard, instelbaar |
|
Stuurpen
|
Concept EX, verstelbaar |
|
Stuur
|
Concept EX Riser,Concept EX Ergo Riser |
|
Toelaatbaar gewicht
|
170 kg |
|
Zadel
|
Selle Royal Essenza |
|
Achterdemper
|
Nee |
|
Derailleur achter
|
Shimano Deore XT |
|
Zadelpen
|
Concept EX |
|
Pedalen
|
Urban Aluminium, met anti-slipbescherming en reflector |
|
Voornaaf
|
Shimano Alivio MT400, Steekas 15x100mm |
|
Trapas
|
Integrated in Drive Unit |
|
Achternaaf
|
Shimano Alivio MT400, 12x142 mm doorgaande as |
|
Banden
|
Schwalbe Big Ben, 50-622 |
|
Bagagedrager
|
Racktime Systeem bagagedrager |
|
Veerweg
|
50 mm |
|
Remsysteem
|
schijfremmen |
|
Type Versnelling
|
derailleur |
|
Batterij watt-uur
|
540 Wh |
|
Ketting
|
Shimano CN-LG50 |
|
Veerweg voorvork
|
50 mm |
|
Grip Description
|
Herrmans Click |
| |
Wheel diameter / Size |
S |
M |
L |
XL |
|
Stand Over Height (°) |
S |
M |
L |
XL |
| A |
Grootte (MM) |
430 |
480 |
530 |
580 |
| B |
Effective Top Tube (MM) |
592 |
597 |
606 |
615 |
| C |
Head Tube Angle (°) |
72 |
72 |
72 |
72 |
| D |
Effective Seat Tube Angle (°) |
73 |
73 |
73 |
73 |
| E |
Chainstay length (MM) |
485 |
485 |
485 |
485 |
| F |
Bottom bracket drop (MM) |
65 |
65 |
65 |
65 |
| G |
Head Tube Length (MM) |
160 |
170 |
180 |
190 |
| H |
Fork construction height (MM) |
469 |
468 |
468 |
468 |
| I |
Pre-raked fork (MM) |
45 |
45 |
45 |
45 |
| J |
Wheelbase length (MM) |
1111 |
1117 |
1126 |
1135 |
| K |
Stack (MM) |
649 |
658 |
667 |
677 |
| L |
Reach (MM) |
393 |
396 |
402 |
408 |
