Specificaties
Alles wat je moet weten over deze fiets
|
Motor
|
Bosch Performance Line 36 V / 250 W / 65 Nm |
|
Weergave
|
Bosch Purion, LCD display with walk assist |
|
Accu
|
Bosch PowerTube Li-Ion 36 V |
|
Aandrijfsysteem
|
Bosch |
|
Lader
|
Bosch, 4A |
|
Schakeling
|
Shimano Alivio, 9-speed |
|
Versteller
|
Shimano Alivio |
|
Cranks
|
Concept |
|
Achtertandwiel
|
Shimano HG200, 9-speed |
|
Overbrenging
|
front: 18, rear: 11-34 |
|
Remklauw
|
Tektro M285, hydraulic disc brake |
|
Remschijf
|
180 |
|
Vorlamp
|
Herrmans H-Black MR8, LED |
|
Achterlicht
|
Busch & Müller Line Small, LED |
|
Beeld
|
Integrale 0.5, aluminium |
|
Wielset
|
Nee |
|
Velgen
|
RODI Blackrock, geöst |
|
Voorvork
|
SR Suntour NEX E25, lockout, 9mm QR |
|
Spatbord
|
Nee |
|
Stuurpen
|
Concept EX, adjustable |
|
Standaard model
|
rear stand, adjustable |
|
Stuur
|
Concept EX Riser,Concept EX Ergo Riser |
|
Toelaatbaar gewicht
|
130 kg |
|
Zadel
|
Selle Royal Verve,Selle Royal Rampage,Kalkhoff Sport Comfort |
|
Achterdemper
|
Nee |
|
Zadelpen
|
Concept EX |
|
Derailleur achter
|
Shimano Alivio |
|
Pedalen
|
MTB Flat, alloy with reflector |
|
Trapas
|
Integriert in Mittelmotor |
|
Banden
|
Schwalbe Smart Sam, 47-622 |
|
Type Versnelling
|
Nee |
|
Remsysteem
|
Nee |
|
Ketting
|
Shimano HG53 |
|
Gewicht in kg
|
24,4,24,7 |
|
Veerweg van de voorvork
|
50 mm |
|
Grip Description
|
Ergon GA30,Ergon GA20 |
| |
Wheel diameter / Size |
S |
M |
L |
XL |
|
Stand Over Height (°) |
S |
M |
L |
XL |
| A |
Grootte (MM) |
430 |
480 |
530 |
580 |
| B |
Effective Top Tube (MM) |
588.2 |
597.1 |
606 |
614.9 |
| C |
Head Tube Angle (°) |
72 |
72 |
72 |
72 |
| D |
Effective Seat Tube Angle (°) |
73 |
73 |
73 |
73 |
| E |
Chainstay length (MM) |
485 |
485 |
485 |
485 |
| F |
Bottom bracket drop (MM) |
65 |
65 |
65 |
65 |
| G |
Head Tube Length (MM) |
160 |
170 |
180 |
190 |
| H |
Fork construction height (MM) |
468 |
468 |
468 |
468 |
| I |
Pre-raked fork (MM) |
45 |
45 |
45 |
45 |
| J |
Wheelbase length (MM) |
1107.5 |
1116.6 |
1125.7 |
1125.7 |
| K |
Stack (MM) |
648.4 |
657.9 |
667.4 |
676.9 |
| L |
Reach (MM) |
390 |
396 |
402 |
408 |
* Subject to technical modification without notice. Errors and omissions excepted.
