Trekking frames with optimised geometry for short and long distances
Easy-Tubeless ready: robust, high-profile hollow section rim
Busch + Müller IQ-XS front light with 70 lux output
Shimano XT groupset
Specifications
Everything you need to know about this bike
Bike Typ
No
Shifting system
Shimano Deore XT, 30-speed
Shifter
Shimano Deore XT T8000
Crankset
Shimano Deore XT T8000
Rear sprocket description
Shimano HG81
Gear Ratio
front: 48/36/26, rear: 11-34
Brakes
Shimano Deore XT T8000, hydraulic disc brake
Brake rotors
180
Headlight
Herrmans H-Black Pro, 100 Lux
Taillight
integrated in carrier
Wheelset
No
Frame
Trekking 1.6, alloy
Wheelsize
28"
Rims
Concept EX 570, easy tubeless ready
Fender
plastic, with edge protector
Fork
SR Suntour NCX-D, lockout
Stem
Aluminium, a-head, rigid
Kickstand
rear stand, adjustable
Permissible Total Weight
130 kg
Handlebar
Concept EX Riser
Shock
No
Saddle
Selle Royal Lookin
Rear derailleur
Shimano Deore XT
Seatpost
Concept EX, aluminium
Pedals
Urban Light, with anti slip protection and reflector
Front Hub
Concept Sport dynamo hub, QR
Bottom Bracket
BSA
Rear hub
Shimano Deore M6010, 12x142 mm
Tires
Schwalbe Marathon Supreme, 37-622
Carrier
Racktime System Carrier
Bike weight incl. battery in kg.
ca. 15 kg,15,5
Travel
50 mm
Gear System
derailleur
Brake
disc brake
Chain
Shimano CN-HG95
Bike weight incl. battery in kg.
ca. 15 kg,15,5
Travel Fork
50 mm
Grip Description
Ergon GP1
Wheel diameter / Size
S
M
L
XL
A
Size (MM)
450
500
550
600
B
Effective Top Tube (MM)
588
597
606
615
C
Head Tube Angle (°)
72
72
72
72
D
Effective Seat Tube Angle (°)
73
73
73
73
E
Chainstay length (MM)
455
455
455
455
F
Bottom bracket drop (MM)
65
65
65
65
G
Head Tube Length (MM)
160
170
180
190
H
Fork construction height (MM)
465
465
465
465
I
Pre-raked fork (MM)
45
45
45
45
J
Wheelbase length (MM)
1077
1086
1095
1104
K
Stack (MM)
648
658
667
677
L
Reach (MM)
390
396
402
408
