Bosch Intuvia LCD, with control panel and walk assist
Battery Ampere hours
13,4 Ah
Battery
Bosch PowerTube Li-Ion 36 V
Drive system
Bosch
Range
Less than 100 km,100 - 150 km
Charger
Bosch, 2A
Shifting system
Shimano Nexus, 5-speed
Shifter
Shimano Nexus
Crankset
aluminium
Gear Ratio
front: 46, rear: 28,vorne: 42, hinten: 28
Brake caliper
Shimano MT200, 2-piston, hydraulic disc brake
Brake rotors
180
Headlight
Herrmans H-Black MR4, LED
Taillight
Herrmans H-Trace, LED
Frame
Integrale 0.1, aluminium
Wheelsize
28"
Fork
SR Suntour NEX E25 HLO, lockout
Fender
plastic, with edge protector
Stem
alloy, adjustable
Kickstand
rear stand, adjustable
Handlebar
Tour, Aluminium
Permissible Total Weight
130 kg
Saddle
Selle Royal Essenza Plus
Seatpost
Patent, suspension
Pedals
Comfort, aluminium
Front Hub
Shimano TX505, QR
Bottom Bracket
Integrated in Drive Unit
Rear hub
Shimano Nexus, 5 speed
Tires
Schwalbe Energizer Active Plus, 50-622
Carrier
Tour, aluminium
Bike weight incl. battery in kg.
ca. 28 kg
Travel
63 mm
Gear System
gearhub
Brake
disc brake
Battery Watt-hours
500 Wh
Chain
Gates Carbondrive CDX
Bike weight incl. battery in kg.
ca. 28 kg
Grip Description
Ergon GC10
Wheel diameter / Size
S
M
L
XL
Stand Over Height (°)
S
M
L
XL
A
Size (MM)
450
500
550
600
B
Effective Top Tube (MM)
587
596
605
408
C
Head Tube Angle (°)
72
72
72
72
D
Effective Seat Tube Angle (°)
73
73
73
73
E
Chainstay length (MM)
480
480
480
480
F
Bottom bracket drop (MM)
65
65
65
65
G
Head Tube Length (MM)
160
170
180
190
H
Fork construction height (MM)
462
462
462
462
I
Pre-raked fork (MM)
44
44
44
44
J
Wheelbase length (MM)
1100
1110
1119
1128
K
Stack (MM)
645
655
664
674
L
Reach (MM)
390
396
402
408
* Subject to technical modification without notice. Errors and omissions excepted.
