Handling via top tube integrated Set /ON/OFF button
Battery
Groove Next Li-Ion, 252 Wh
Drive system
Groove
Charger
Charger, 2A
Shifting system
Shimano Tourney TX, 8-speed
Shifter
Shimano Altus
Crankset
aluminium
Rear sprocket description
Shimano Altus
Gear Ratio
front: 46, rear: 11-32
Brake caliper
Shimano MT200, 2-piston, hydraulic disc brake
Brake rotors
160
Headlight
Herrmans H-Black MR4, LED with stand light
Taillight
AXA Blueline, LED with stand light
Frame
Urban Integrated, Aluminium
Wheelset
No
Rims
Concept EX 570, easy tubeless ready
Fork
Aluminum with lowrider compatible
Fender
plastic, with edge protector
Stem
Aluminium, adjustable
Kickstand
rear stand, adjustable
Handlebar
Tour, Aluminium
Permissible Total Weight
130 kg
Saddle
Kalkhoff Sport Comfort
Shock
No
Seatpost
Concept
Rear derailleur
Shimano Tourney
Pedals
Comfort, with anti slip protection and reflector
Bottom Bracket
BSA
Tires
Schwalbe Spicer, 40-622
Carrier
Tour, aluminium
Gear System
derailleur
Brake
disc brake
Chain
KMC X8
Travel of suspension fork
No
Grip Description
Herrmans Basic
Wheel diameter / Size
S
M
L
XL
Stand Over Height (°)
S
M
L
XL
A
Size (MM)
410
460
510
560
B
Effective Top Tube (MM)
576.9
586
598
609
C
Head Tube Angle (°)
72
72
72
72
D
Effective Seat Tube Angle (°)
73
73
73
73
E
Chainstay length (MM)
430
430
430
430
F
Bottom bracket drop (MM)
60
60
60
60
G
Head Tube Length (MM)
135
145
160
170
H
Fork construction height (MM)
418
418
418
418
I
Pre-raked fork (MM)
45
45
45
45
J
Wheelbase length (MM)
1041
1051
1063
1074
K
Stack (MM)
572
582
596
605
L
Reach (MM)
402
408
416
424
* Subject to technical modification without notice. Errors and omissions excepted.
