ENDEAVOUR 7.B BELT
Bosch CX drive, the 4th generation with 85 Nm
Integrated Bosch PowerTube battery with 625 Watt hour capacity
Range up to 125 km*
Infinitely variable Enviolo Trekking gear hub with belt drive
Features
ENDEAVOUR 7.B BELT
A bike that turns every trip into an exciting adventure
Specifications
Everything you need to know about this bike
Motor
Bosch Performance Line CX, 36 V / 250 W / 85 Nm
Display
Bosch Kiox colour display with walk assist
Battery Ampere hours
17,4 Ah
Battery
Bosch PowerTube Li-Ion 36 V
Drive system
Bosch
Charger
Bosch, 4A
Shifting system
Enviolo Trekking
Shifter
Enviolo Trekking
Crankset
aluminium
Gear Ratio
front: 46, rear: 22
Brake caliper
Shimano MT420, 4-piston, hydraulic disc brake
Brake rotors
180
Headlight
Supernova E3 Mini 2
Taillight
Spanninga Pimento
Frame
Integrale 1.5, aluminium
Wheelset
No
Wheelsize
27"
Rims
Rodi TRYP35, with double eyelets
Fork
Suntour Mobie25 Air, lockout, 15 mm thru axle
Fender
aluminium, painted
Stem
Concept EX, adjustable
Kickstand
rear stand, adjustable
Handlebar
Concept EX Riser
Permissible Total Weight
130 kg
Saddle
Ergon SM10
Seatpost
Concept EX, aluminium
Pedals
Urban Light, with anti slip protection and reflector
Front Hub
Shimano Alivio MT400, 15x100 mm with QR
Bottom Bracket
Integrated in Drive Unit
Rear hub
Enviolo Trekking
Tires
Schwalbe Marathon Almotion 55-584
Carrier
Racktime Commuter
Bike weight incl. battery in kg.
ca. 28 kg
Travel
63 mm
Gear System
gearhub
Brake
disc brake
Battery Watt-hours
625 Wh
Chain
Gates Carbondrive CDX
Bike weight incl. battery in kg.
ca. 28 kg
Travel of suspension fork
63 mm
Grip Description
Ergon GA30
Wheel diameter / Size
S
M
L
XL
Stand Over Height (°)
S
M
L
XL
A
Size (MM)
430
480
530
580
B
Effective Top Tube (MM)
595
604
613
622
C
Head Tube Angle (°)
71
71
71
71
D
Effective Seat Tube Angle (°)
73
73
73
73
E
Chainstay length (MM)
485
485
485
485
F
Bottom bracket drop (MM)
47
47
47
47
G
Head Tube Length (MM)
160
170
180
190
H
Fork construction height (MM)
460
460
460
460
I
Pre-raked fork (MM)
45
45
45
45
J
Wheelbase length (MM)
1133
1142
1151
1161
K
Stack (MM)
621
630
640
649
L
Reach (MM)
405
411
417
423
* Subject to technical modification without notice. Errors and omissions excepted.
