Bosch Performance Line Smart System, 36 V / 250 W / 75 Nm
Display
Bosch Intuvia 100, with LED Remote
Battery Ampere hours
15,1 Ah,20,1 Ah
Battery
Bosch PowerPack Li-Ion 36 V
Drive system
Bosch
Range
Less than 100 km,100 - 150 km
Charger
Bosch, 4A
Shifting system
Shimano Acera, 8-speed
Shifter
Shimano Altus
Crankset
aluminium
Rear sprocket description
No
Gear Ratio
front: 42, rear: 11-34
Brake caliper
Tektro T280, 2-piston, hydraulic disc brake
Brake rotors
180
Headlight
Herrmans MR GO, LED, 20 Lux
Taillight
Herrmans H-Trace, LED
Frame
E-Comfort, aluminium
Wheelset
No
Wheelsize
28"
Rims
High Profile, with eyelets, aluminum
Fork
Suntour NEX E25 HLO 50mm
Fender
plastic, with edge protector
Stem
Aluminium, adjustable
Kickstand
rear stand, adjustable
Handlebar
Tour, Aluminium
Permissible Total Weight
130 kg
Saddle
Selle Royal TCM
Shock
No
Seatpost
Concept EX, aluminium
Rear derailleur
Shimano Acera
Pedals
Aluminium, with anti slip protection and reflector
Front Hub
KT TC7F, Centerlock
Bottom Bracket
No
Rear hub
KT TC7R, Centerlock, 10-speed
Tires
CST Platinum, 50-622
Carrier
MIK Rear Carrier
Travel
75 mm
Gear System
derailleur
Brake
disc brake
Battery Watt-hours
545 Wh,725 Wh
Chain
KMC X8
Travel of suspension fork
75 mm
Grip Description
Ergon GP10,Ergon GC10
Wheel diameter / Size
XS
S
M
L
XL
Stand Over Height (°)
XS
S
M
L
XL
A
Size (MM)
400
450
500
550
XL
B
Effective Top Tube (MM)
615.4
631.8
642.2
651.6
XL
C
Head Tube Angle (°)
68
69
69.5
69.5
XL
D
Effective Seat Tube Angle (°)
79.9
79.9
79.9
79.9
XL
E
Chainstay length (MM)
527
527
527
527
XL
F
Bottom bracket drop (MM)
60
60
60
60
XL
G
Head Tube Length (MM)
185
185
195
200
XL
H
Fork construction height (MM)
497
497
497
497
XL
I
Pre-raked fork (MM)
45
45
45
45
XL
J
Wheelbase length (MM)
1242.7
1246.9
1251.9
1261.7
XL
K
Stack (MM)
677.8
682.9
694.8
718.2
XL
L
Reach (MM)
421
436
443
451
XL
* Subject to technical modification without notice. Errors and omissions excepted.
