Aluminium, with anti slip protection and reflector
Front Hub
Shimano TX505, QR
Bottom Bracket
No
Rear hub
Shimano TX505, QR
Tires
Schwalbe Energizer Plus Tour, 47-622,Schwalbe Energizer Plus Tour, 50-622
Carrier
Aluminium with Snap-IT System
Bike weight incl. battery in kg.
ca. 24 kg,ca. 27 kg
Travel
50 mm,63 mm
Gear System
derailleur
Brake
disc brake
Battery Watt-hours
500 Wh,400 Wh
Chain
KMC X8
Bike weight incl. battery in kg.
ca. 24 kg,ca. 27 kg
Travel of suspension fork
63 mm
Grip Description
Ergon GP10,Ergon GC10
Wheel diameter / Size
XS
S
M
L
XL
Stand Over Height (°)
XS
S
M
L
XL
A
Size (MM)
400
450
500
550
600
B
Effective Top Tube (MM)
615.4
570
642.2
595
610
C
Head Tube Angle (°)
68
71
69.5
71.5
71.5
D
Effective Seat Tube Angle (°)
79.9
74
79.9
73
72.5
E
Chainstay length (MM)
527
475
527
475
475
F
Bottom bracket drop (MM)
60
60
60
55
55
G
Head Tube Length (MM)
185
135
195
170
220
H
Fork construction height (MM)
497
460
497
460
460
I
Pre-raked fork (MM)
45
55
45
55
55
J
Wheelbase length (MM)
1242.7
1111
1251.9
1120
1129
K
Stack (MM)
677.8
612
694.8
638
685
L
Reach (MM)
421
394
443
400
394
* Subject to technical modification without notice. Errors and omissions excepted.
