From €3,249.00
  • Bosch Performance Line smart system drive with 75 Nm
  • Integrated Bosch PowerTube battery with choice of 625 or 500 Watt hour capacity
  • Range up to 120 km*
  • Shimano MT200 hydraulic disk brakes

Everything you need to know about this bike

Bike Typ No
Motor Bosch Performance Line Smart System, 36 V / 250 W / 75 Nm
Display Bosch Intuvia 100, with LED Remote
Battery Ampere hours 13,4 Ah,17,4 Ah
Battery Bosch PowerTube Li-Ion 36 V
Drive system Bosch
Range Less than 100 km,100 - 150 km
Charger Bosch, 4A
Shifting system Shimano Alivio, 9-speed
Shifter Shimano Alivio
Crankset aluminium
Rear sprocket description No
Gear Ratio front: 42, rear: 11-34
Brake caliper Shimano MT200, hydraulic disc brake
Brake rotors 180
Headlight Herrmans H-Black MR4, LED
Taillight Herrmans H-Trace, LED
Frame Integrale 3|23
Wheelset No
Wheelsize 28"
Rims High Profile, with eyelets, aluminum
Fork SR Suntour NEX E25 HLO, lockout
Fender plastic, with edge protector
Stem Aluminium, adjustable
Kickstand rear stand, adjustable
Handlebar Tour, Aluminium
Permissible Total Weight 130 kg
Saddle Selle Royal Nuvola Unitec
Shock No
Seatpost aluminium patent, rigid
Rear derailleur Shimano Alivio M3100
Pedals Comfort, aluminium
Front Hub Shimano TX505, QR
Bottom Bracket Integrated in Drive Unit
Rear hub Shimano TX505, QR
Tires Schwalbe Energizer Plus Tour, 50-622
Carrier MIK Rear Carrier
Travel 63 mm
Gear System derailleur
Brake hydraulische Scheibenbremse
Battery Watt-hours 500 Wh,625 Wh
Chain KMC X9
Travel of suspension fork 63 mm
Grip Description Ergon GP10,Ergon GC10
  Wheel diameter / Size S M L XL
Stand Over Height (°) S M L XL
A Size (MM) 450 500 550 600
B Effective Top Tube (MM) 596 599.9 608.7 617.6
C Head Tube Angle (°) 70 70 70 70
D Effective Seat Tube Angle (°) 73 73 73 73
E Chainstay length (MM) 494 494 486 486
F Bottom bracket drop (MM) 65 65 65 65
G Head Tube Length (MM) 165 175 185 195
H Fork construction height (MM) 475 475 475 475
I Pre-raked fork (MM) 44 44 44 44
J Wheelbase length (MM) 1141.1 1145.5 1154.8 1164.2
K Stack (MM) 657.4 666.8 676.2 685.7
L Reach (MM) 444 450 456 462
* Subject to technical modification without notice. Errors and omissions excepted.

Your security package


Our proven quality "Made in Germany" – In addition to the 10-year warranty on all e-bike and S-Pedelec frames, we are offering to extend the 2-year warranty by a further 12 months for all Impulse motors and BMZ power packs manufactured from 2017 onwards and purchased on or after 1 August 2017.


Kalkhoff has one of the most modern and largest test laboratories in Europe. Frames, forks, seat supports, wheels, brakes and other components are tested on 30 machines spread over 40 square metres - up to 2,000 parts a year.
